Two-way detector switch with female connector terminal SSCL Series

First lever-type detector switch in the industry with a female connector terminal
Use of a double-sided sliding contact realizes high contact reliability in shock/vibration environments
No sound is made during operation, contributing to silent operation of electronic devices

Automotive switch for detecting, for example, the direction of door key rotation or the opening/closing of the doors and trunk
Detection of mechanical drive operation in automotive devices and home appliances

Items	Specifications
Max./Min. rating (resistive load)	100mA 12V DC / 50μA 5V DC
Operating force	0.7N max.
Operating life	50,000 cycles
Inclination angle (max. on one side)	36°
