Main power ON/OFF, Mode selection, Start can be completed with one switch



• Two shafts are combined. Center shaft : Push switch (Unlatching), Outside shaft : Encoder
• Zero standby power consumption is available by auto-off function with relay movement due to built-in both AC and DC contact in the push switch
• Both pulse and absolute output are available for the installed encoder

• Dryer, Micro wave oven, IH cooking heater, Washing machine

Items	Specifications
Rating AC contact	1A/16A 250V～
Rating DC contact	20mA 12V DC
Rating Encoder	0.1A 12V DC
Operating life（Encoder）	30,000cycles
Push travel	1.85mm



Document	File Type	File Size	Download
Datasheet	PDF	404 KB
