Highly efficient power inductor with a proprietary new magnetic material for large current.



• Liqualloy™ low core loss material for high-efficiency power supplies
• For large current
• Excellent low heat generation characteristics and high reliability due to low direct current resistance (DCR)
• Metal composite structure allows a compact size

• CPU and graphics power supply circuits for notebook PCs
• DC/DC converters for servers and game consoles, etc.
• POL（Point of Load） power supplies

Product No.	Inductance (μＨ) at 100kHz	Direct Current Resistance (mΩ)	Rated Current
			Saturation Current △L/L=30%(A)max.	Heat Rating Current △T=40℃ (A)max.
GLMDR3601A	0.36 ± 20%	0.76 ± 7%	31	32
GLMDR4501A	0.45 ± 20%	1.10 ± 7%	25	27



Document	File Type	File Size	Download
Datasheet	PDF	129 KB
