Alps Electric low-profile 35mm size ring type encoder EC35A Series

2-phase incremental type encoder for general use.
Low-profile design with a 4.5mm body height.
Devices such as switches and LEDs can be mounted into its center therefore contributing to the final set's flexibility of design.
Good operation feeling and less shaft wobble.

Volume control and function change for car AV equipment and navigation systems; temperature control for HVACs; menu selection for home appliances such as washing machines and microwave ovens; and other applications.

Items	Specifications
Rating	10mA 5V DC
Operating life	50,000cycles
Operating temperature range	-40℃ to +85℃
Detent torque	18±7mN･m
Detent number/ Pulse number	30 detents/ 15 pulses
