Specifications


XP-40
XP-41
XP-42
XP-43
Function
 Standard
Lightning Protection & Tamper
Sensitivity Adjustment & Tamper
Lightning Protection, Tamper & Sensitivity Adjustment
Power Requirement
10.6 to 16VDC (Normal 12VDC)
Current Draw
25mA maximum

PIR Detector
Dual element
Pulse Count
2/4 pulses (selectable)
Warm Up Period
38 secs. max. (red LED blinks during warm up)
Alarm Period
2 secs., ±0.4 secs.
Detection Display
Red LED monitor (on/off selectable)
Alarm Output
NC dry contact, 30VDC, 0.5A, 5W max.
Tamper Contact
NO
NC dry contact, 30VDC, 0.5A max.
Mounting Heaight
5.0 to 8.5 ft. (1.5 to 2.6m)
Operating Temperature
+14° F to +122° F; Humidity: 95% max.
Dimensions
3.9" (98mm) L; 2.5" (64mm) W; 1.7" (42mm) H
Weight
3.0 oz. (83.5g)
