Images	Title	File Size	Download
Catalog & Brochures
	Product Overview 2023	3.2 MB	Download
Product Specific Brochures
	Antennas Adam Tech’s RF Antennas are an optimal solution for any application transmitting or receiving electromagnetic waves. This series is headlined by WiFi, LTE, and GPS antennas, offered as either embedded or external. Designed with versatility in mind, they are available in a variety of lengths, mounting orientations, and specifications. Adam Tech is committed to providing reliable solutions to the wide world of wireless communication.	885 KB	Download
	Electric Vehicle Charger Cables Adam Tech’s EV Charger Cables provide a durable and efficient solution to electric vehicle charging. Both Type 1 and Type 2 plugs are available to meet multiple EV charging needs. Equipped with cable lengths of 3 and 5 meters, vehicles can be charged from a variety of distances. In addition, all Adam Tech EV chargers are TUV safety approved. Adam Tech is committed to providing reliable and cost-effective charging solutions to the growing electric vehicle industry.	836 KB	Download
	Fiber Optic Adapters Adam Tech’s Fiber Optic Adapters are designed to link fiber optic patch cables. They properly align the individual fibers of two patch cables during the mating process, ensuring reliable connections in optical communication systems. These adapters enable multiple devices to communicate simultaneously. Adam Tech’s broad offering includes APC, FC, LC, MPO, PC, and SC adapters. Simplex, duplex, 4-plex, and 8-plex adapters are available to connect various quantities of fibers.	1.5 MB	Download
	High Speed Board-to-Board Connectors Adam Tech expands its board-to-board series with High Speed Board-to-Board Connectors. The signal integrity of these connectors is ideal for any high speed board-to-board application. With both surface mount contacts and a surface mount ground plane, these connectors are designed with optimal electrical performance in mind. This product has a stack height of 5mm (.197"] and is available with either a 0.5mm (0.020"] or 0.8mm (0.031"] pitch.	1.3 MB	Download
	High Speed Data FAKRA Adam Tech enhances its FAKRA (Fachkreis Automobil) series with its High Speed Data FAKRA connectors. One pin FAKRA connectors are no longer adequate for applications that require higher data transmission rates. HSD FAKRA four pin connectors meet those demands with their 100 ohm impedance- controlled system, offering high speeds and top-quality signal transmission. These high speed connectors are designed to satisfy RF requirements in various telematic and multimedia applications.	1.2 MB	Download
	High Speed Modular Plugs Adam Tech’s High Speed Modular Plugs support device bandwidth requirements with dependability and speed. These plugs boast speeds of Cat 5, Cat 6, Cat 6a, and Cat 8. The series is supported by accessories such as strain relief, plastic hoods, and plating options. Adam Tech is dedicated to supplying signal transmission applications with top-quality modular products.	1.2 MB	Download
	High Speed USB4 Connector Adam Tech’s line of USB4 connectors and cables boast speeds up to 40Gbps, making them the fastest USB products in the industry. These parts are backwards compatible with the speeds of USB 3.2 and 2.0 Type-C. Other features include two-lane operation with existing USB Type-C cables, multiple data and display protocols, and the ability to simultaneously transfer both audio and video over the same connection.	949 KB	Download
	Mini FAKRA Connectors Adam Tech’s High Speed Mini FAKRA Connectors and Cable Assemblies support the automotive industry with the next generation of coaxial technology. These products support data transmission rates up to 20 Gbps, and frequencies up to 9 GHz. Designed with space saving in mind, they require 80% less installation space than standard FAKRAs. Adam Tech’s offering includes multiple color-coded board side plugs and double-ended mini FAKRA jack cable assemblies. Mini FAKRA to standard FAKRA cable assemblies are also available, bridging the gap between the two generations.	1.1 MB	Download
	Power Connectors Adam Tech IEC & Mini IEC Series AC Inlets and Outlets are primary power receptacles designed, manufactured, tested and approved to UL, CSA and other applicable international specifications including IEC-60320 and CEE-22. Adam Tech offers a wide variety of body styles, shapes and orientations to accommodate most class I & II applications with two or three blade contacts in both IEC and Mini-lEC configurations. Mounting choices include screw holes and snap-in versions and four termination styles. Options of ganged ports or receptacle with integral fuse holder are also available.	742 KB	Download
	Power Line Filters Adam Tech’s EMI/RFI Power Line Filters are designed to block the incoming and outgoing interference of high-frequency signals. This allows devices to run without interruption. This broad product line offers a voltage rating of 115/250VAC, and current ratings ranging from 1A to 20A. A variety of options are available, including outline, mounting, termination, and switches.	2.3 MB	Download
	Push Pull Connectors Adam Tech’s comprehensive line of Push Pull Connectors consists of metal and plastic connectors, elbow sockets, and bend reliefs. Each product type is offered in a variety of options, including positions, mounting, and size. Specialty waterproof push pull connectors are also available with ratings of IP67 and IP68. Adam Tech Push Pull Connectors are ideal for any application requiring easy, secure connections.	2.7 MB	Download
	RJ45 Modular Jacks with Magnetics Adam Tech’s High Speed Integrated Magnetics Jacks provide fast and reliable solutions to increasing bandwidth requirements. These RJ45s are offered in 1G, 2.5G, 5G, and 10G Base-T speeds, equipping them to be supported by Cat 5e, Cat 6, and Cat 6a ethernet cables. The series includes a variety of options including LED lights, shielding, and magnetics. Adam Tech is committed to accommodating the advancing technology of signal transmission.	853 KB	Download
	Spring Loaded & Magnetic Adam Tech Pogo Pins and Connectors (spring loaded terminals) consist of a pin, barrel, and steel spring with or without an insulator carrier. They are used in many industries across a wide range of applications to make a secure, high reliability connection. This series is highly customizable to meet specific stroke lengths, heights, and electrical capabilities. High-temp plastics are used for our insulators and unlimited molding designs allow for many different shapes and styles to be created for specific applications.	962 KB	Download
	SIM Card Connectors Adam Tech’s SIM (Subscriber Identification Module) Card Connector series offes a wide range of SIM, Micro SIM, and Nano SIM card connectors. These reliable, low profile connectors provide the necessary gateway between SIM cards and mobile devices. They are available in a variety of insertion and removal methods including hinged cover, push in-pull out, and push in-push out.	1.2 MB	Download
	Switches Adam Tech’s board switch range offers a variety of options, including termination style, circuit, function, and actuator types. Specialty switches are available, such as ruggedized and sealed waterproof. The Adam Tech Switch line provides the versatility necessary to be integrated into a wide range of market applications.	3.0 MB	Download
	Transceivers Adam Tech’s Fiber Optic Transceivers transmit and receive data with speed and reliability. This diverse product line includes SFP, SFP+, SFP28, QSFP+, and QSFP28 pluggable modules. With data rates ranging from 1.25G to 100G and transmissions between 10km and 100m, a wide range of applications are covered. Most of the offering is composed of single fiber bidirectional transceivers, who’s paired A and B parts transmit and receive in two different directions of the center wavelength to cooperatively achieve bi-directional transmission of optical signals on a fiber.	1.2 MB	Download
	Ultra High Speed HDMI 2.1 Connector and Cables Adam Tech’s Ultra High Speed HDMITM 2.1 connector and cables provide uncompressed 8K video with HDR, and support bandwidth speeds up to 48 Gbps. They also support 4K video, eARC (Enhanced Audio Return Channel), VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), QFT (Quick Frame Transport), and QMS (Quick Media Switching). The cables are available in lengths of 3ft, 6ft, 10ft, and 16.5ft.	676 KB	Download
	USB-A Over USB-C Combo Connector Adam Tech diversifies its USB series with the combination of a USB Type-A and USB Type-C port in one connector. The dual-port design minimizes the space required to house two USB ports, which alleviates capacity contraints in product design. In addition, it increases the volume and diversity of devices that are compatible with its accompanied products. This multifunctional connector is offered in both a vertical mount and right angle mount orientation in order to accommodate any application.	923 KB	Download
	Waterproof Adam Tech’s Waterproof Connector series is a broad range of M Style, Circular, and RJ45/USB mated sets withIP ratings ranging from IP66 - IP68. These connectors are offered in different pin counts and keying styles and can be used in many applications.	977 KB	Download
	1.27mm Board to Board Stacking Connectors Adam Tech’s 1.27mm Board-to- Board Stacking and Coplanar Connectors are an optimal board stacking solution. The 1.27mm pitch enables PCB connections in parallel, perpendicular, or side-by-side arrangements. Their secure mating allows for PCB connection distances ranging from .315” [8.0mm] to .728” [18.5mm]. These connectors are available in both vertical and right angle mounting orientation, with the vertical connectors offered in low, mid, or high profile. They are ideal for products in various industries including consumer electronics, industrial, and medical.	977 KB	Download
