Typical Specifications

Rating(max.)(/ min.) (Resistive load) 1mA 5V DC / 50μA 3V DC
Contact resistance (Initial / After operating life) 2Ω max. / 5Ω max.
Operating force 0.35N max.
Operating life Without load 50,000cycles
With load 50,000cycles(1mA 5V DC)

Downloads

Document File Type File Size Download
SSCQ Series Datasheet PDF 943 KB
